powerCON True 1 NAC3MX-W-TOP Male IP65

powerCON True 1 NAC3MX-W-TOP Male IP65

NEUTRIK

  • £6.69


The Neutrik NAC3MX-W-TOP is a Male powerCON TRUE1 16A true mains connector for outdoor applications with an IP65 protection class so you don't have to worry about water damage or dirt/dust causing faults in your network. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to guarantee a safe power connection. The powerCON TRUE1 TOP is a connector with breaking capacity (CBC), i.e. it can be connected or disconnected under load or live.

Neutrik NAC3MX-W-TOP Features

  • Heavy duty sealed power connector for harsh and demanding environment

  • Uses high impact UV-resistant materials

  • Lockable 16 A single phase connector (USA: 20 A)

  • Extremely robust and reliable

  • ENEC certified according to IEC 60320

  • IP65 rating and certified outdoor protection to UL 50E enclosure type 4 (in mated condition)

  • True mains connector with breaking capacity (CBC)

  • Easy and reliable twist lock system

  • Unique Neutrik cable retention

  • UL498 certified

Specifications

Neutrik NAC3MX-W-TOP Specifications

  • Contact resistance: ≤ 3 mΩ

  • Dielectric strength: 4 kVdc / 2.8 kVac

  • Insulation resistance: 0,1 GΩ (after damp heat test IEC 68-2-30)

  • Number of electrical contacts: 2 + PE

  • Rated current per contact: 16 A rms (USA: 20 A)

  • Rated voltage: 250 V ac

  • Cable O.D.: 6 - 12 mm

  • Lifetime: > 5000 mating cycles

  • Wiresize: 1.0 - 2.5 mm²

  • Wiresize: 12 AWG

  • Contact plating: 2 µm Ag

  • Contacts: CuNi1Si0.2

  • Insert: Polyamide (PA 6.6 30 % GR)

  • Locking element: ZuAl4Cu1

  • Shell: Polyamide (PA 6.6 30 % GR)

  • Strain relief: Polyacetal (POM)

  • Flammability: UL 94 V-0

  • Protection class: IP65, UL50E enclosure type 4 (mated)

  • Temperature range: -30 °C - +80 °C
